    VL4000 BEAMWASH



    The Vari-Lite VL4000 BEAMWASH is designed to provide designers, rental companies, venues and productions with a complement of fixtures offering unlimited design possibilities.



    Without the need to change lenses, the VL4000 BEAMWASH combines stunning wash capabilities with intense beam functionality and the ability to produce a powerful collimated shaft of light. Producing 43,000 lumens in standard mode (35,000 studio mode), the VL4000 BEAMWASH uses a 1200W lamp to provide incredible point-of-source imagery through its 254mm (10”) front lens.



    When used in wash mode, the luminaire provides a 10 to 60 degree zoom range. By simply adjusting a DMX value, the VL4000 BEAMWASH can shift to an intense beam luminaire with an amazing 4 to 40 degree beam angle, or a Shaft fixture for a powerful, collimated ray of light where the 4 degree beam angle can be further reduced to near zero.

    Features

    • 1200W Philips MSR Gold FastFit lamp
    • Swap from wash to beam with no lens change
    • Image projection is sharper than standard beam fixtures
    • Studio mode for quitter application uses
    • Multiple hanging rail points
    • Dual opposing color wheels
    • Infinity CMY cross fading system
    • 2 fixed color wheels; five positions each
    • Variable CTO color temperature correction
    • Two gobo wheels
      Seven rotatable, indexable positions plus open
    • 43,000 lumens (standard mode), 35,000 lumens (studio mode)
    • One animation wheel
      Rotating indexable pattern with variable motion control
    • Wash mode
      Zoom range from 10-60° (6:1 optics system)
    • Beam mode
      Zoom range from 4-40° (10:1 optics system)
    • Shaft mode
      Zoom range from 4° to near 0°
    • 5 facet step prism
    • Beam and shaft mode indexing and rotating lenticular effect
    • Wash mode indexing and rotating beam shaping
